Wiring Method For Elevator Photoelectric Switch
Three-wire and four-wire elevator photoelectric switches are two common types that have some differences in wiring and functionality. Three-Wire Elevator Photoelectric Switch: The three-wire sensor has two wiring options to meet the requirements of the elevator.The yellow and blue wires have the same function, and you can choose either based on personal preference. It can […]
AS380 Series Elevator Integrated Controller Inverter
AS380 Series Elevator Integrated Controller Inverter Model No. Rated Capacity Rated Output Current Input Voltage Motor Power AS380 2S01P1 2.3kVA 6A AC380V 1.1KW AS380 2S02P2 4.6kVA 12A AC380V 2.2KW AS380 2S03P7 6.9kVA 18A AC380V 3.7KW AS380 4T02P2 4.7kVA 6.2A AC380V 2.2KW AS380 4T03P7 6.9kVA 9A AC380V 3.7KW AS380 4T05P5 8.5kVA 13A AC380V 5.5KG AS380 4T07P5 […]
How To Adjust MX10 MX18 Brake
MX10 / MX18 brake is the most commonly used in many MonoSpace elevator systems. How to Install and adjust it? Actually, there are twobrakes for gearless host machine MX10/MX18, and need to be adjusted one by one, or will lead to the elevator cabin slided. Install one brake onto the traction machinefirst(The other one should be […]
Nice3000new Elevator PG Card
Monarch provides 4 types PG card models for Nice3000new : MCTC-PG-A2 MCTC-PG-D MCTC-PG-E MCTC-PG-F1 Different PG cards for different encoder types MCTC-PG-A2: It is used to adapt to the pull and open-collector incremental encoders MCTC-PG-D : It is used to adapt to the UVW differential encoder and applied to synchronous motor. It usually needs 5V […]
Elevator Oil Cup
What is an elevator oil cup? The elevator oil cup also knowed as oil box or oil can, is an automatic lubricating device installed on the guide shoe to lubricate the guide rail and guide shoe. The installation of oil cup shall be carried out after cleaning the elevator hoistway. Usually, it is divided into counterweight […]
What Wire Rope Is Used In Elevators?
According to the using, the elevator steel wire ropes can be divided into traction machine steel wire rope; overspeed governor steep wire rope and elevator door machines steel wire ropes. Seale. It is the most frequently used in elevator rope because of its thick outer wire and strong resistance against external wear. Like 6x19S+FC,8x19S+FC Warrington. The thickness of the […]
Elevator Traveling Cable
What is an elevator traveling cable? Elevator Traveling Cable is a link between the elevator car and controller. All power and signal is transmitted through it.It is a multi-conductor wire cable They are two basic types of traveling cables in elevators: Round traveling cable Flat traveling cable Features: Conductor Material: Multi-strand ultra-fine flexible finely stranded oxygen-free […]
Monarch NICE3000 new Fault Codes Troubleshooting
Faults E65 、E66 or E74 may be reported during the debugging or running the elevator. Failure analysis: UCMP Function: protection device to prevent accidental movement of the car, and detect whether the car has moved through the MCTC-SCB-A/A1/C module? When the system detects unexpected displacement, the control system immediately stops output and reports E65 fault. […]
