PSC-100B Elevator Power Supply
Model No.: PSC-100B/PSC-100B-C
27.6Vdc Power Supply Battery Charger, UPS Function Enclosed Type
Specifications
Input Voltage:90~264Vac
Output Voltage #1:27.6Vdc
Output #1 Max Current:3.5 Amps
Output Voltage #2:27.6Vdc
Output #2 Max Current:1.25 Amps
Max Power:100 Watts
Features
Relay contact signal output for AC OK & battery low
Protections: short circuit / over load / over voltage
Ideal AC/DC power supply for security systems, access systems, monitoring systems, emergency lighting systems, alarm systems & DC UPS systems
