| Suspension | 2：1/1：1 |
| Voltage | 380V |
| Ploe | 32 |
| Rating | S5（40%） |
| INS.Class | F |
| IP Code | IP41 |
| Brake | DC110V 2×1.5A |
| Max.Static Load | 3500kg |
| Weight | 350kg |
| Specification | Load (kg) |
Lift Speed (m/s) |
Sheave Diam (mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
| Suspension2:1 | |||||||||
| GTW9A-82P0A | 800 | 2.0 | Φ480 | 5×Φ10×16 | 22.3 | 592 | 159 | 42.4 | 9.9 |
| GTW9A-82P5A | 2.5 | 28.4 | 592 | 200 | 53.3 | 12.4 | |||
| GTW9A-102P0 | 1000/1050 | 2.0 | Φ480 | 6×Φ10×16 | 30 | 780 | 159 | 42.4 | 13 |
| GTW9A-102P5 | 2.5 | 35.6 | 780 | 200 | 53.3 | 16..3 | |||
| GTW9A-111P0 | 1150 | 1.0 | Φ400 | 6×Φ10×16 | 17 | 750 | 96 | 25.6 | 7.5 |
| GTW9A-111P5 | 1.5 | 26 | 750 | 144 | 38.4 | 11.3 | |||
| GTW9A-111P6 | 1.6 | 26 | 750 | 153 | 40.8 | 12 | |||
| GTW9A-111P7 | 1.75 | 28 | 750 | 167 | 44.5 | 13.1 | |||
| GTW9A-112P0 | 2.0 | 33 | 750 | 192 | 51.2 | 15.1 | |||
| GTW9A-121P0 | 1250 | 1.0 | Φ400 | 6×Φ10×16 | 18.5 | 810 | 96 | 25.6 | 8.1 |
| GTW9A-121P5 | 1.5 | 28.3 | 810 | 144 | 38.4 | 12.2 | |||
| GTW9A-121P6 | 1.6 | 28.3 | 810 | 153 | 40.8 | 13 | |||
| GTW9A-121P7 | 1.75 | 30.3 | 810 | 167 | 44.5 | 14.2 | |||
| GTW9A-122P0 | 2.0 | 35.6 | 810 | 192 | 51.2 | 16.3 | |||
| Suspension1:1 | |||||||||
| GTW9A-61P5-1 | 630 | 1.5 | Φ400 | 6×Φ10×16 | 16.2 | 810 | 72 | 19.2 | 6.1 |
| GTW9A-61P6-1 | 1.6 | 16.2 | 810 | 77 | 20.5 | 6.5 | |||
| GTW9A-61P7-1 | 1.75 | 17.2 | 810 | 84 | 22.4 | 7.1 | |||
| GTW9A-62P0-1 | 2.0 | 18.5 | 810 | 96 | 25.6 | 8.1 | |||
