FRD40K Passenger Lift Gearless Traction Machine 630-1000KG
Permanent magnet synchronous gearless traction machine
Supply Voltage: AC380V
Traction Ratio:2:1
Protection Grade:IP41
Elevator Speed:1.0-1.75m/s
Rated Capacity:630-1000kg
Brake:DC110V,2*1.5A
The maximum axial load:3000kg
duty type:S5-40%
AF-FRD40K (2:1) Series Permanent Magnet Synchronous Gearless Traction Machine Select Table:
| Model | Load | Speed | Torque | Sheave Dia | Rope Dia | Groove | Distance Between Grooves | Power | Rated Voltage | Rated Current | Frequency | Rated Speed | Pole Parts |
| (kg) | (m/s） | (Nm) | (mm) | (mm) | (pcs) | (Kw) | (V) | (A) | (Hz) | (m/s) | |||
| AF-FRD40K-0630-100 | 630kg | 1.00m/s | 430Nm | 400mm | 10mm | 4pcs | 15 | 4.2Kw | 380V | 10A | 23.5Hz | 95m/s | 16 |
| AF-FRD40K-0630-150 | 1.50m/s | 6.3Kw | 14A | 38.1Hz | 143m/s | ||||||||
| AF-FRD40K-0630-175 | 1.75m/s | 7.3Kw | 16A | 44.5hz | 167m/s | ||||||||
| AF-FRD40K-0800-100 | 800kg | 1.00m/s | 540Nm | 400mm | 10mm | 5pcs | 15 | 5.3Kw | 380V | 13A | 25.3Hz | 95m/s | 16 |
| AF-FRD40KT-0800-150 | 1.50m/s | 8.0Kw | 18A | 38.1Hz | 143m/s | ||||||||
| AF-FRD40K-0800-175 | 1.75m/s | 9.3Kw | 21A | 44.5hz | 167m/s | ||||||||
| AF-FRD40K-0100-100 | 1000kg | 1.00m/s | 640Nm | 400mm | 10mm | 5pcs | 15 | 6.5Kw | 380V | 16A | 25.3Hz | 95m/s | 16 |
| AF-FRD40K-0100-150 | 1.50m/s | 9.8Kw | 23A | 38.1Hz | 143m/s | ||||||||
| AF-FRD40K-0100-175 | 1.75m/s | 11.4Kw | 26A | 44.5hz | 167m/s |
