Elevator Switching Power Supply
Porducts features:
Multiple protection, steady output,smart chip, copper transformer,high capacitance, high heat dissipation
| Model No. | Output | Rated Current | Rated Power | Input | Item Size(mm) |
| LRS-35-5 | 5V | 7A | 35W | 85-264VAC | 99*82*30 |
| LRS-35-12 | 12V | 3A | 36W | 85-264VAC | 99*82*30 |
| LRS-35-24 | 24V | 1.5A | 36W | 85-264VAC | 99*82*30 |
| LRS-35-48 | 48V | 0.8A | 38W | 85-264VAC | 99*82*30 |
| LRS-50-5 | 5V | 10A | 50W | 85-264VAC | 99*82*30 |
| LRS-50-12 | 12V | 4.2A | 50W | 85-264VAC | 99*82*30 |
| LRS-50-24 | 24V | 2.2A | 52W | 85-264VAC | 99*82*30 |
| LRS-50-48 | 48V | 1.1A | 52W | 85-264VAC | 99*82*30 |
| LRS-75-5 | 5V | 14A | 70W | 85-264VAC | 99*82*30 |
| LRS-75-12 | 12V | 6A | 72W | 85-264VAC | 99*82*30 |
| LRS-75-24 | 24V | 3.2A | 76W | 85-264VAC | 99*82*30 |
| LRS-75-48 | 48V | 1.6A | 76W | 85-264VAC | 99*82*30 |
| LRS-100-5 | 5V | 18A | 90W | 85-264VAC | 127*97*30 |
| LRS-100-12 | 12V | 8.5A | 102W | 85-264VAC | 127*97*30 |
| LRS-100-24 | 24V | 4.5A | 108W | 85-264VAC | 127*97*30 |
| LRS-100-36 | 36A | 2.8A | 100W | 85-264VAC | 127*97*30 |
| LRS-100-48 | 48V | 2.3A | 110W | 85-264VAC | 127*97*30 |
| LRS-150-12 | 12V | 12.5A | 150W | 85-264VAC | 159*97*30 |
| LRS-150-24 | 24V | 6.5A | 156W | 85-264VAC | 159*97*30 |
| LRS-150F-5 | 5V | 22A | 110W | 85-264VAC | 159*97*30 |
| LRS-150F-48 | 48V | 3.3A | 158W | 85-264VAC | 159*97*30 |
| LRS-200-5 | 5V | 40A | 200W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-200-12 | 12V | 17A | 204W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-200-24 | 24V | 8.8A | 211W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-200-36 | 36A | 5.9A | 212W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-200-48 | 48V | 4.4A | 211W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-350-5 | 5V | 60A | 300W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-350-12 | 12V | 29A | 348W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-350-24 | 24V | 23.2A | 348W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-350-36 | 36A | 14.6A | 350W | 90-132VAC 180-264VAC |
215*115*30 |
| LRS-350-48 | 48V | 7.3A | 350W | 90-132VAC 180-264VAC |
215*115*30 |
