GDX machine need to work with GUDA grooved belt,Belt Clip, Counter Pulley, Belt Breaking Detect,
Bake Release, Belt Lock.
| load | 800kg |
| Voltage | 380V |
| Suspension | 2:1 |
| Center Height | 132mm |
| Weight | 165kg |
| Max.Static Load | 4000kg |
| Brake | DC110V 2*1.1A |
| Duty | S5 40% |
| GENERAL DATA | Load | Lift speed | Phase Voltage | Sheave dia | Poles | Traction bel qty | Rated power | Rated speed | Rated torque | Frequency | Rated Voltage | Rated Current |
| GDX132-800-10-34 | 800kg | 1m/s | 3/380V | 104mm | 10P | 3n | 5.4kW | 367r/min | 141N·m | 30.6Hz | 318V | 12.5A |
| GDX132-800-16-34 | 800kg | 1.6m/s | 3/380V | 404mm | 10P | 3n | 8.6kW | 588r/min | 140N·m | 49Hz | 322V | 18.6A |
| GDX132-800-17.5-34 | 800kg | 1.75m/s | 3/380V | 104mm | 10P | 3n | 9.4kW | 643r/min | 140N·m | 53.6Hz | 328V | 19.9A |
| GDX132-800-20-34 | 800kg | 2m/s | 3/380V | 104mm | 10P | 3n | 10.7kW | 735r/min | 139N·m | 61.3Hz | 323V | 23.2A |
