Notes: GDX machine need to work with GUDA grooved belt,Belt Clip, Counter Pulley, Belt Breaking Detect,
Bake Release, Belt Lock.
| GENERAL DATA | Load | Lift speed | Phase Voltage | Sheave dia | Poles | Traction belt qty | Rated power | Rated speed | Rated torque | Frequency | Rated Voltage | Rated Current |
| GDX112-630-4-12 | 630kg | 0.4m/s | 1/220V | 86mm | 10P | 3n | 1.7kW | 178r/min | 91N·m | 14.8Hz | 169V | 9.2A |
| GDX112-630-4-34 | 630kg | 0.4m/s | 3/380V | 86mm | 10P | 3n | 1.7kW | 178r/min | 91N·m | 14.8Hz | 251V | 6.2A |
| GDX112-630-6.3-12 | 630kg | 0.63m/s | 1/220V | 86mm | 10P | 3n | 2.7kW | 280r/min | 92N·m | 23.3Hz | 163V | 13.6A |
| GDX112-630-6.3-34 | 630kg | 0.63m/s | 3/380V | 86mm | 10P | 3n | 2.7kW | 280r/min | 92N·m | 23.3Hz | 316V | 7.0A |
| GDX112-630-10-12 | 630kg | 1.0m/s | 1/220V | 86mm | 10P | 3n | 4.2kW | 444r/min | 90N·m | 37.0Hz | 167V | 18.8A |
| GDX112-630-10-34 | 630kg | 1.0m/s | 3/380V | 86mm | 10P | 3n | 4.2kW | 444r/min | 90N·m | 37.0Hz | 278V | 11.3A |
| load | 630kg |
| Voltage | 220 / 380V |
| Suspension | 2:1 |
| Center Height | 112mm |
| Weight | 82kg |
| Max.Static Load | 2000kg |
| Brake | DC110V 2*0.6A |
| Duty | S5 40% |
