| Suspension | 2：1 |
| Voltage | 380V |
| Ploe | 20 |
| Rating | S5（40%） |
| INS.Class | F |
| IP Code | IP41 |
| Brake | DC110V 2×0.9A |
| Max.Static Load | 3000kg |
| Weight | 245kg |
| Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
| ER1L-61POA | 630 | 1.0 | φ320 | 5×φ8×12 | 9.5 | 318 | 120 | 20 | 4 |
| ER1L-61P5A | 1.5 | 15 | 330 | 179 | 29.8 | 6.2 | |||
| ER1L-61P6A | 1.6 | 15 | 330 | 192 | 32 | 6.6 | |||
| ER1L-61P7A | 1.75 | 15.8 | 330 | 209 | 34.8 | 7.2 | |||
| ER1L-62POA | 2.0 | 18 | 330 | 239 | 39.8 | 8.3 | |||
| ER1L-81POA | 800 | 1.0 | φ320 | 6×φ8×12 | 14 | 401 | 120 | 20 | 5 |
| ER1L-81P5A | 1.5 | 20.2 | 420 | 179 | 29.8 | 7.9 | |||
| ER1L-81P6A | 1.6 | 20.2 | 420 | 192 | 32 | 8.4 | |||
| ER1L-81P7A | 1.75 | 21.7 | 420 | 209 | 34.8 | 9.2 | |||
| ER1L-82POA | 2.0 | 23.5 | 420 | 239 | 39.8 | 10.5 | |||
| ER1L-101POAD | 1000 | 1.0 | φ320 | 7×φ8×12 | 15.4 | 482 | 120 | 20 | 6.1 |
| ER1L-101P5AD | 1.5 | 22.3 | 506 | 179 | 29.8 | 9.5 | |||
| ER1L-101P6AD | 1.6 | 26.8 | 506 | 192 | 32 | 10.2 | |||
| ER1L-101P7AD | 1.75 | 26.8 | 506 | 209 | 34.8 | 11.1 | |||
| ER1L-102POAD | 2.0 | 28.3 | 506 | 239 | 39.8 | 12.7 | |||
| ER1L-101POA | 1050 | 1.0 | φ320 | 7×φ8×12 | 17.6 | 506 | 120 | 20 | 6.4 |
| ER1L-101P5A | 1.5 | 26 | 525 | 179 | 29.8 | 9.8 | |||
| ER1L-101P6A | 1.6 | 26 | 525 | 192 | 32 | 10.6 | |||
| ER1L-101P7A | 1.75 | 27.5 | 525 | 209 | 34.8 | 11.5 | |||
| ER1L-102POA | 2.0 | 29.4 | 525 | 239 | 39.8 | 13.1 | |||
| ER1L-111POA | 1150 | 1.0 | φ320 | 7×φ8×12 | 18.2 | 615 | 120 | 20 | 7.7 |
| ER1L-111P5A | 1.5 | 30 | 615 | 179 | 29.8 | 11.5 | |||
| ER1L-111P6A | 1.6 | 30 | 615 | 192 | 32 | 12.4 | |||
| ER1L-111P7A | 1.75 | 30 | 615 | 209 | 34.8 | 13.5 | |||
| ER1L-112POA | 2.0 | 33.6 | 615 | 239 | 39.8 | 15.4 |
