Suspension | 2:1 |
Voltage | 380V |
Ploe | 20 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 2×1.41A |
Max.Static Load | 2000kg |
Weight | 175kg |
Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
ERSL-41P0A | 450 | 1.0 | φ320 | 4xφ8×12 | 8.3 | 228 | 120 | 20 | 2.9 |
ERSL-41P5A | 1.5 | 10.8 | 240 | 179 | 29.8 | 4.5 | |||
ERSL-41P6A | 1.6 | 12.5 | 240 | 192 | 32 | 4.8 | |||
ERSL-41P7A | 1.75 | 12.5 | 240 | 209 | 34.8 | 5.3 | |||
ERSL-61P0A | 630 | 1.0 | φ320 | 5xφ8×12 | 11 | 318 | 120 | 20 | 4 |
ERSL-61P5A | 1.5 | 14.9 | 336 | 179 | 29.8 | 6.3 | |||
ERSL-61P6A | 1.6 | 18 | 336 | 192 | 32 | 6.8 | |||
ERSL-61P7A | 1.75 | 18 | 336 | 209 | 34.8 | 7.4 |
