3000~5000KG GTN2C Elevator Spare Parts Gearless Traction Machine

Product Name Elevator Traction Machine
Type Elevator Spare Parts
AF-ID NO. AF-GTN2C
Model NO. GTN2C
Delivery Time 7~10 Working days
Delivery DHL,TNT,FedEx,Air,Sea
Payment T/T,Western Union,Paypal

Hot Product

Main Product

Suspension 2:1
Voltage 380V
Ploe 32
Rating S5(40%)
INS.Class F
IP Code IP41
Brake DC110V 2×2.2A
Max.Static Load 14000kg
Weight 1900kg



Spec Load
(kg)
Lift Speed
(m/s)
Sheave
Diam(mm)
Rope Sheave
(mm)
Current
(A)
Torque
(Nm)
Rated Speed
(rpm)
Frequency
(Hz)
Power
(kW)
GTN2C-301P0 3000 1.0 φ520 8×φ13×20 48 2400 73 19.5 18.3
GTN2C-301P5 1.5 69 2400 110 29.3 27.6
GTN2C-301P7 1.75 79 2400 128 34.1 32.2
GTN2C-302P0 2.0 90 2400 147 39.2 36.9
GTN2C-401P0 4000 1.0 φ520 10×φ13×20 60 3200 73 19.5 24.5
GTN2C-401P5 1.5 88 3200 110 29.3 36.9
GTN2C-401P7 1.75 101 3200 128 34.1 42.9
GTN2C-402P0 2.0 118 3200 147 39.2 49.3
GTN2C-501P0 5000 1.0 φ520 12×φ13×20 72 4000 73 19.5 30.6
GTN2C-501P5 1.5 105 4000 110 29.3 46.1
GTN2C-501P7 1.75 124 4000 128 34.1 53.6
GTN2C-502P0 2.0 142 4000 147 39.2 61.6



3000~5000KG GTN2C Elevator Spare Parts Gearless Traction Machine
