| Suspension | 2：1 |
| Voltage | 380V |
| Ploe | 24 |
| Rating | S5（40%） |
| INS.Class | F |
| IP Code | IP41 |
| Brake | DC110V 2×2.2A |
| Max.Static Load | 36000kg |
| Weight | 3000kg |
| Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Double Roping |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
| GTN3-165P0-1 | 1600 | 5.0 | φ700 | 14×中16×20 | YES | 123 | 3750 | 137 | 27.4 | 53.9 |
| GTN3-166P0-1 | 6.0 | 141 | 3750 | 164 | 32.8 | 64.6 | ||||
| GTN3-167P0-1 | 7.0 | 165 | 3750 | 192 | 38.4 | 75.4 | ||||
| GTN3-168P0-1 | 8.0 | 195 | 3750 | 218 | 43.6 | 85.6 | ||||
| GTN3-205P0-1 | 2000 | 5.0 | φ700 | 16×φ16×20 | YES | 147 | 4700 | 137 | 27.4 | 67.2 |
| GTN3-206P0-1 | 6.0 | 174 | 4700 | 164 | 32.8 | 80.6 | ||||
| GTN3-207P0-1 | 7.0 | 213 | 4700 | 192 | 38.4 | 94 | ||||
| GTN3-208P0-1 | 8.0 | 238 | 4700 | 218 | 43.6 | 107 |
