Suspension | 2:1 |
Voltage | 380V |
Ploe | 20 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 2×1.5A |
Max.Static Load | 4500kg |
Weight | 455kg |
Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
ER3-131POB | 1350 | 1.0 | φ320 | 9×φ8×12 | 22.8 | 735 | 119 | 19.9 | 9.2 |
ER3-131P5B | 1.5 | 33 | 735 | 179 | 29.8 | 13.8 | |||
ER3-131P6B | 1.6 | 33 | 735 | 192 | 32 | 14.8 | |||
ER3-131P7B | 1.75 | 36.8 | 735 | 209 | 34.8 | 16.1 | |||
ER3-132POB | 2.0 | 41.5 | 735 | 239 | 39.8 | 18.4 | |||
ER3-161POB | 1600 | 1.0 | φ320 | 10×φ8×12 | 27 | 870 | 119 | 19.9 | 10.8 |
ER3-161P5B | 1.5 | 39 | 870 | 179 | 29.8 | 16.3 | |||
ER3-161P6B | 1.6 | 39 | 870 | 192 | 32 | 17.5 | |||
ER3-161P7B | 1.75 | 43.5 | 870 | 209 | 34.8 | 19 | |||
ER3-162P0B | 2.0 | 49 | 870 | 239 | 39.8 | 21.8 |
