| Suspension | 2：1/1：1 |
| Voltage | 380V |
| Ploe | 32 |
| Rating | S5（40%） |
| INS.Class | F |
| IP Code | IP41 |
| Brake | DC110V 2×2.2A |
| Max.Static Load | 800kg |
| Weight | 910kg |
| Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
| Suspension2:1 | |||||||||
| GTW12-201P0 | 2000 | 1.0 | φ520 | 6xφ13×20 | 29.2 | 1735 | 73 | 19.5 | 13.3 |
| GTW12-201P7 | 1.75 | 48.7 | 1735 | 128 | 34.1 | 23.3 | |||
| GTW12-202P0 | 2.0 | 54.6 | 1735 | 147 | 39.2 | 26.7 | |||
| GTW12-251P0 | 2500 | 1.0 | φ520 | 7xφ13×20 | 35.7 | 2170 | 73 | 19.5 | 16.6 |
| GTW12-251P7 | 1.75 | 59.8 | 2170 | 128 | 34.1 | 29.1 | |||
| GTW12-252P0 | 2.0 | 68.3 | 2170 | 147 | 39.2 | 33.4 | |||
| Suspension1:1 | |||||||||
| GTW12-121P0-1 | 1250 | 1.0 | φ485 | 8xφ12×18 | 19.7 | 1925 | 40 | 10.7 | 8.1 |
| GTW12-121P6-1 | 1.6 | 28.2 | 1925 | 63 | 16.8 | 12.7 | |||
| GTW12-121P7-1 | 1.75 | 30.4 | 1925 | 69 | 18.4 | 13.9 | |||
| GTW12-122P0-1 | 2.0 | 35.2 | 1925 | 79 | 21.1 | 15.9 | |||
| GTW12-131P0-1 | 1350 | 1.0 | φ485 | 8xφ12×18 | 21.3 | 2080 | 40 | 10.7 | 8.7 |
| GTW12-131P6-1 | 1.6 | 30.5 | 2080 | 63 | 16.8 | 13.7 | |||
| GTW12-131P7-1 | 1.75 | 32.8 | 2080 | 69 | 18.4 | 15 | |||
| GTW12-132P0-1 | 2.0 | 38 | 2080 | 79 | 21.1 | 17.2 | |||
