Suspension | 2:1 |
Voltage | 380V |
Ploe | 20 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 2×2.1A |
Max.Static Load | 6000kg |
Weight | 880kg |
Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
ER6D-121P0 | 1250 | 1.0 | φ440 | 7×φ10×16 | 20.2 | 860 | 87 | 14.5 | 7.8 |
ER6D-121P6 | 1.6 | 30.6 | 860 | 139 | 23.2 | 12.6 | |||
ER6D-121P7 | 1.75 | 33 | 860 | 153 | 25.5 | 13.8 | |||
ER6D-122P0 | 2.0 | 36.8 | 860 | 174 | 29 | 15.7 | |||
ER6D-131P0 | 1350 | 1.0 | φ440 | 7×φ10×16 | 21.8 | 920 | 87 | 14.5 | 8.4 |
ER6D-131P6 | 1.6 | 33.1 | 920 | 139 | 23.2 | 13.4 | |||
ER6D-131P7 | 1.75 | 35.5 | 920 | 153 | 25.5 | 14.8 | |||
ER6D-132P0 | 2.0 | 39.8 | 920 | 174 | 29 | 16.8 | |||
ER6D-161P0 | 1600 | 1.0 | φ440 | 8×φ10×16 | 26.3 | 1120 | 87 | 14.5 | 10.2 |
ER6D-161P6 | 1.6 | 39.8 | 1120 | 139 | 23.2 | 16.3 | |||
ER6D-161P7 | 1.75 | 42.9 | 1120 | 153 | 25.5 | 17.9 | |||
ER6D-162P0 | 2.0 | 47.9 | 1120 | 174 | 29 | 20.5 | |||
ER6D-221P0 | 2250 | 1.0 | φ440 | 8×φ10×16 | 36.2 | 1530 | 87 | 14.5 | 13.9 |
ER6D-221P6 | 1.6 | 53.7 | 1530 | 139 | 23.2 | 22.3 | |||
ER6D-221P7 | 1.75 | 59.5 | 1530 | 153 | 25.5 | 24.5 | |||
ER6D-222P0 | 2.0 | 66.7 | 1530 | 174 | 29 | 27.9 |
