12.1 Inch Elevator Cabin Video Multi-media Advertising LCD Screen Display Panel
| Model No. | AMIS-S080 | AMIS-S101 | AMIS-S104 | AMIS-S121 | AMIS-S150 | AMIS-S190 |
| Spec | 8″ | 10.1″ | 10.4″ | 12.1″ | 15″ | 19″ |
| Resolution | 800×600 | 1280×800 | 800×600 | 800×600 | 1021×768 | 1366×768 |
| Effective display area WXH(mm) |
162×121.5 | 216×135.6 | 211.2×158.4 | 246×184.5 | 304.1×228.1 | 409.8×230.4 |
| Voltage/Power | DC24V≤5W | DC24V≤5W | DC24V≤6 | DC24V≤10 | DC24V≤12 | DC24V≤20 |
| Horizontal Viewing Angle | -70°～70° | -85°～85° | -75°～75° | -80°～80° | -85°～85° | -89°～89° |
| Vertical Viewing Angle | -70°～70° | -85°～85° | -60°～50° | -80°～60° | -85°～70° | -89°～89° |
| Brightness(cd/㎡） | 350 | 450 | 400 | 550 | 450 | 350 |
| Contrast ratio(CR) | 500:1 | 1500:1 | 500:1 | 800:1 | 500:1 | 1000:1 |
| Supply Voltage | DC18～36V | |||||
| Operating Temperature | -10°～50° | |||||
| Operating Ambient Humidity | 10%～90%@40℃ | |||||
| Storage Temperature | -20°～60° | |||||
