Suspension | 2:1 |
Voltage | 380V |
Ploe | 32 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 2×2.1A |
Max.Static Load | 5500kg |
Weight | 450kg |
Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed rpm) |
Frequency (Hz) |
Power (kW) |
ER5-111P0 | 1150 | 1.0 | φ400 | 6×φ10×16 | 19.3 | 730 | 96 | 25.6 | 7.3 |
ER5-111P5 | 1.5 | 33 | 730 | 143 | 38.1 | 10.9 | |||
ER5-111P6 | 1.6 | 33 | 730 | 153 | 40.8 | 11.7 | |||
ER5-111P7 | 1.75 | 33 | 730 | 167 | 44.5 | 12.8 | |||
ER5-112P0 | 2.0 | 37.2 | 730 | 191 | 50.9 | 14.6 | |||
ER5-112P5 | 2.5 | 47 | 730 | 239 | 63.7 | 18.3 | |||
ER5-113P0 | 3.0 | φ450 | 6×φ10×16 | 56.2 | 820 | 255 | 68 | 21.9 | |
ER5-121P0 | 1250 | 1.0 | φ400 | 7×φ10×16 | 22.3 | 795 | 96 | 25.6 | 8 |
ER5-121P5 | 1.5 | 37.5 | 795 | 143 | 38.1 | 11.9 | |||
ER5-121P6 | 1.6 | 37.5 | 795 | 153 | 40.8 | 12.7 | |||
ER5-121P7 | 1.75 | 37.5 | 795 | 167 | 44.5 | 13.9 | |||
ER5-122P0 | 2.0 | 41 | 795 | 191 | 50.9 | 15.9 | |||
ER5-122P5 | 2.5 | 50.7 | 795 | 239 | 63.7 | 19.9 | |||
ER5-123P0 | 3.0 | φ450 | 7×φ10×16 | 57.5 | 890 | 255 | 68 | 23.8 | |
ER5-131P0 | 1350 | 1.0 | φ400 | 7×φ10×16 | 24 | 855 | 96 | 25.6 | 8.6 |
ER5-131P5 | 1.5 | 40.3 | 855 | 143 | 38.1 | 12.8 | |||
ER5-131P6 | 1.6 | 40.3 | 855 | 153 | 40.8 | 13.7 | |||
ER5-131P7 | 1.75 | 40.3 | 855 | 167 | 44.5 | 15 | |||
ER5-132P0 | 2.0 | 44.1 | 855 | 191 | 50.9 | 17.1 | |||
ER5-132P5 | 2.5 | 54.5 | 855 | 239 | 63.7 | 21.4 | |||
ER5-133P0 | 3.0 | φ450 | 7×φ10×16 | 62.3 | 965 | 255 | 68 | 25.8 | |
ER5-161P0 | 1600 | 1.0 | φ400 | 8×φ10×16 | 27 | 1015 | 96 | 25.6 | 10.2 |
ER5-161P5 | 1.5 | 47 | 1015 | 143 | 38.1 | 15.2 | |||
ER5-161P6 | 1.6 | 47 | 1015 | 153 | 40.8 | 16.3 | |||
ER5-161P7 | 1.75 | 47 | 1015 | 167 | 44.5 | 17.7 | |||
ER5-162P0 | 2.0 | 50.4 | 1015 | 191 | 50.9 | 20.3 | |||
ER5-162P5 | 2.5 | 62 | 1015 | 239 | 63.7 | 25.4 |
