Suspension | 2:1 |
Voltage | 380V |
Ploe | 20 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 2×1.8A |
Max.Static Load | 3800kg |
Weight | 360kg |
Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kw) |
ER2D-111POC | 1150 | 1.0 | φ320 | 8×φ8×12 | 18.3 | 630 | 119 | 19.9 | 7.8 |
ER2D-111P5C | 1.5 | 28 | 630 | 179 | 29.8 | 11.8 | |||
ER2D-111P6C | 1.6 | 28 | 630 | 192 | 32 | 12.7 | |||
ER2D-111P7C | 1.75 | 30.5 | 630 | 209 | 34.8 | 13.8 | |||
ER2D-112P0C | 2.0 | 33.5 | 630 | 239 | 39.8 | 15.8 | |||
ER2D-121POC | 1250 | 1.0 | φ320 | 8×φ8×12 | 19.8 | 680 | 119 | 19.9 | 8.5 |
ER2D-121P5C | 1.5 | 30.3 | 680 | 179 | 29.8 | 12.7 | |||
ER2D-121P6C | 1.6 | 30.3 | 680 | 192 | 32 | 13.8 | |||
ER2D-121P7C | 1.75 | 32.8 | 680 | 209 | 34.8 | 14.9 | |||
ER2D-122POC | 2.0 | 38.9 | 680 | 239 | 39.8 | 17 |
