Suspension | 2:1/1:1 |
Voltage | 380V |
Ploe | 32 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 3×1.5A |
Max.Static Load | 11000kg |
Weight | 755kg |
Specification | Load (kg) |
Lift Speed (m/s) |
Sheave Diam (mm) |
Rope Sheave (mm) |
Double Roping |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
Quantity of brake |
Suspension2:1 | |||||||||||
GTW10L-102P0 | 1000 | 2.0 | φ410 | 12xφ10×14 | YES | 27.8 | 670 | 186 | 49.6 | 13 | 2 |
GTW10L-102P5 | 2.5 | φ485 | 12xφ10×14 | YES | 34.1 | 790 | 197 | 52.5 | 16.3 | 2 | |
GTW10L-121P0 | 1250 | 1.0 | φ410 | 12xφ10×14 | YES | 17.8 | 840 | 93 | 24.8 | 8.2 | 2 |
GTW10L-121P5 | 1.5 | 28.2 | 840 | 140 | 37.3 | 12.3 | |||||
GTW10L-121P6 | 1.6 | 28.2 | 840 | 149 | 39.7 | 13.1 | |||||
GTW10L-121P7 | 1.75 | 31 | 840 | 163 | 43.5 | 14.3 | |||||
GTW10L-122P0 | 2.0 | 34.5 | 840 | 186 | 49.6 | 16.4 | |||||
GTW10L-122P5 | 2.5 | φ485 | 12xφ10×14 | YES | 42.6 | 990 | 197 | 52.5 | 20.4 | 2 | |
GTW10L-131P0 | 1350 | 1.0 | φ410 | 14xφ10×14 | YES | 19 | 910 | 93 | 24.8 | 8.9 | 2 |
GTW10L-131P5 | 1.5 | 30.2 | 910 | 140 | 37.3 | 13.3 | |||||
GTW10L-131P6 | 1.6 | 30.2 | 910 | 149 | 39.7 | 14.2 | |||||
GTW10L-131P7 | 1.75 | 33.7 | 910 | 163 | 43.5 | 15.5 | |||||
GTW10L-132P0 | 2.0 | 38.1 | 910 | 186 | 49.6 | 17.7 | |||||
GTW10L-132P5 | 2.5 | φ485 | 14xφ10×14 | YES | 46.7 | 1070 | 197 | 52.5 | 22.1 | 3 | |
GTW10L-161P0 | 1600 | 1.0 | φ410 | 14xφ10×14 | YES | 22.8 | 1080 | 93 | 24.8 | 10.5 | 3 |
GTW10L-161P5 | 1.5 | 36.5 | 1080 | 140 | 37.3 | 15.8 | |||||
GTW10L-161P6 | 1.6 | 36.5 | 1080 | 149 | 39.7 | 16.9 | |||||
GTW10L-161P7 | 1.75 | 39.8 | 1080 | 163 | 43.5 | 18.4 | |||||
GTW10L-162P0 | 2.0 | 45.5 | 1080 | 186 | 49.6 | 21 | |||||
GTW10L-162P5 | 2.5 | φ485 | 14xφ10×14 | YES | 58.1 | 1270 | 197 | 52.5 | 26.2 | 3 | |
GTW10L-201P0 | 2000 | 1.0 | φ410 | 18xφ10×14 | YES | 30.2 | 1350 | 93 | 24.8 | 13.1 | 3 |
GTW10L-201P5 | 1.5 | 46.9 | 1350 | 140 | 37.3 | 19.8 | |||||
GTW10L-201P6 | 1.6 | 46.9 | 1350 | 149 | 39.7 | 21.1 | |||||
GTW10L-201P7 | 1.75 | 50.3 | 1350 | 163 | 43.5 | 23 | |||||
GTW10L-202P0 | 2.0 | 57.9 | 1350 | 186 | 49.6 | 26.3 | |||||
GTW10L-202P5 | 2.5 | φ485 | 18xφ10×14 | YES | 67 | 1550 | 197 | 52.5 | 32 | 3 | |
GTW10L-221P0 | 2250 | 1.0 | φ410 | 18×φ10×14 | YES | 34.9 | 1550 | 93 | 24.8 | 15.1 | 3 |
GTW10L-221P5 | 1.5 | 53.9 | 1550 | 140 | 37.3 | 22.7 | |||||
GTW10L-221P6 | 1.6 | 53.9 | 1550 | 149 | 39.7 | 24.2 | |||||
GTW10L-221P7 | 1.75 | 59 | 1550 | 163 | 43.5 | 26.5 | |||||
GTW10L-222P0 | 2.0 | 67.4 | 1550 | 186 | 49.6 | 30.2 | |||||
Suspension1:1 | |||||||||||
GTW10L-101P0-1 | 1000 | 1.0 | φ410 | 18xφ10×14 | YES | 16.5 | 1350 | 47 | 12.5 | 6.6 | 3 |
GTW10L-101P5-1 | 1.5 | 24.5 | 1350 | 70 | 18.7 | 9.9 | |||||
GTW10L-101P6-1 | 1.6 | 24.5 | 1350 | 75 | 20 | 10.6 | |||||
GTW10L-101P7-1 | 1.75 | 26 | 1350 | 82 | 21.9 | 11.6 | |||||
GTW10L-102P0-1 | 2.0 | 30.2 | 1350 | 93 | 24.8 | 13.1 | |||||
GTW10L-102P5-1 | 2.5 | 36.7 | 1350 | 116 | 30.9 | 16.4 | |||||
GTW10L-111P0-1 | 1150 | 1.0 | φ410 | 20xφ10×12.7 | YES | 18.5 | 1550 | 47 | 12.5 | 7.6 | 3 |
GTW10L-111P5-1 | 1.5 | 27.6 | 1550 | 70 | 18.7 | 11.4 | |||||
GTW10L-111P6-1 | 1.6 | 27.6 | 1550 | 75 | 20 | 12.2 | |||||
GTW10L-111P7-1 | 1.75 | 30.2 | 1550 | 82 | 21.9 | 13.3 | |||||
GTW10L-112P0-1 | 2.0 | 34.9 | 1550 | 93 | 24.8 | 15.1 | |||||
GTW10L-112P5-1 | 2.5 | 42.3 | 1550 | 116 | 30.9 | 18.8 |
