Suspension | 2:1 |
Voltage | 380V |
Ploe | 20 |
Rating | S5(40%) |
INS.Class | F |
IP Code | IP41 |
Brake | DC110V 2×0.89A
DC110V 4×0.69A |
Max.Static Load | 14000kg |
Weight | 1120kg |
Spec | Load (kg) |
Lift Speed (m/s) |
Sheave Diam(mm) |
Rope Sheave (mm) |
Double Roping |
Current (A) |
Torque (Nm) |
Rated Speed (rpm) |
Frequency (Hz) |
Power (kW) |
GTNH2-103P0 | 1000 | 3.0 | φ560 | 10xφ13×18 | YES | 42.8 | 955 | 205 | 34.2 | 20.5 |
GTNH2-104P0 | 4.0 | 56.5 | 955 | 273 | 45.5 | 27.3 | ||||
GTNH2-123P0 | 1250 | 3.0 | φ560 | 10xφ13×18 | YES | 53.3 | 1190 | 205 | 34.2 | 25.5 |
GTNH2-124P0 | 4.0 | 72 | 1190 | 273 | 45.5 | 34 | ||||
GTNH2-133P0 | 1350 | 3.0 | φ560 | 10xφ13×18 | YES | 57.2 | 1290 | 205 | 34.2 | 27.7 |
GTNH2-134P0 | 4.0 | 75.5 | 1290 | 273 | 45.5 | 36.9 | ||||
GTNH2-162P5 | 1600 | 2.5 | φ560 | 12xφ13×18 | YES | 56.5 | 1525 | 171 | 28.5 | 27.3 |
GTNH2-163P0 | 3.0 | 69.5 | 1525 | 205 | 34.2 | 32.7 | ||||
GTNH2-164P0 | 4.0 | 93 | 1525 | 273 | 45.5 | 43.6 | ||||
GTNH2-202P5 | 2000 | 2.5 | φ560 | 12xφ13×18 | YES | 72 | 1910 | 171 | 28.5 | 34.2 |
GTNH2-203P0 | 3.0 | 90 | 1910 | 205 | 34.2 | 41 | ||||
GTNH2-204P0 | 4.0 | 120 | 1910 | 273 | 45.5 | 54.3 |
